| Height | From 3 m to 25 m |
| Apply in | Highway, freeway, Airport ,seaport,plaza,stadium,square,highway,street way etc |
| Shape | Conical, octagonal, square, cylinder |
| Material | Usually Q345B/A572, Q235B/A36, Q460 ,ASTM573 GR65, GR50 ,SS400, SS490, ST52 |
| Lamp power | 20 W- 400 W (HPS/MH) 220V (+-10%) /50Hz |
| Tolerance of the dimension | ± 2% |
| Surface treatment | Hot DIP galvanized Following ASTM A 123, color polyester power or any other standard by client required. |
| Joint of Poles | Insert mode,inner flange mode,face to face joint mode |
| Design of pole | Against earthquake of 8 grade |
| Ultimate tensile strength | 490MPa-620 MPa |
| Thickness | 1 mm to 30 mm |
| Production Process | Raw material test → Cutting →Molding or bending →Welding (longitudinal )→Dimension verify →Flange welding →Hole drilling →Calibration → Galvanization or powder coating ,painting →Recalibration →Thread →Packages |
Classification
Street Light Pole Gantry Pole Traffic Light Pole
CCTV Pole Traffic Sign Pole Anchor Bolt
Application
The gantry poles,which span the highway, As the support of the signal lamp, the CCTV poles, including the main light pole
are composed of steel structures with signal lamp pole is placed on both sides and the cross arm, are used to install road
columns and beams that provide support of the road, including the main pole and monitoring equipment, which is set on one
for LED displays or signs on the road. the transverse arm. side of the intersection.
Manufacture Process
Pole Welding
80 experienced welders with the longest 20 years welding experience
Pole Polish Up
automatic polish process with manual inspection, assure of smoothness
Anchor Bolts
provide cold / hot galvanized, foldable design to save delivery cost
Galvanized Pole Packing
packed with cotton and fixed with tap, provide full protection in delivery
Plastic Powder Coating
automatic powder process with 24 hours high-temperature fixation
Accessories Treatment
we produce all accessories by ourselves to have the control on quality
Workshop
XINTONG is the First company in Eastern China focused on traffic equipment, having 20 years' experience, covering 1/5 Chinese domestic market.
The pole workshop is the largest production workshop, with the best production equipment and experienced operators,to ensure the quality of products.
Plastic Spraying Workshop Pole Rolling Workshop
Flange Making Workshop Automatic Welding Workshop
Project
In Nigeria In Ghana
In Gansu In Philippine In Burundi
